◆產品特性
設計制造標準Design Manafacfure According: ASME B16.34-2004
GB/T 12224-2005
JB/T 8473-1996
連接形式Mode of connection: 內螺紋連接 Female thread type
結構特征Structure character: 錐面密封Conical Sealing
閥門檢驗和試驗Test Standard: API 598-1996
GB/T 13927-1992
材料Material: 碳鋼Carbon steel:
ASTM A105/A105M
GB/T 12228-1989
不銹鋼Stainless steel:
ASTM A276/ASTM A314
GB/T 1220-1992
適用介質Applicable Medium:油Oil,水Water,氣體Air
適用溫度Applicable temperature:-70-240℃ -20-440℃
序號 NO. |
公稱壓力 Norminal pressure |
公稱通徑 DN |
進口 INLET |
出口 OUTLET |
閥體材料 Valve body Material |
1 |
16Mpa |
6 |
1/2”FNPT |
1/2”FNPT |
20# |
2 |
32Mpa |
6 |
R1/2”F |
R1/2”F |
SS304 |
詳細信息歡迎來電咨詢！
