BS000UB69V160P法雷Protistor快熔
BS000UB69V160P法雷Protistor快熔
BS000UB69V160P法雷Protistor快熔
法國Mersen（Ferraz）美爾森熔斷器
深圳市賽晶科技有限公司
電話：0755-86307627 13922810575
傳真：0755-26072303
工作QQ：1727655652 王小姐
企業郵箱：wlj@sz-sunking.com
地址：深圳市南山區南海大道3003號陽光華藝大廈A座14C
優勢供應法國Mersen（Ferraz）/美爾森/法雷/羅蘭Protistor®方體快速熔斷器
Mersen(美爾森)的Protistor®半導體方體快速熔斷器提供設備設計的最大靈活性和電源轉換設備的最終保護。有兩種不同尺寸外形：000和00，gR級別保護根據IEC60269-4和VDE636-23標準制定，這種超快速熔斷的gR級別對半導體器件提供全范圍保護。熔斷器可配備可以裝載的低壓指示微動開關。該產品具有極高的分?jǐn)嗄芰?，同時產生較低的電弧能量（I2t），所有金屬件為非磁性。
Protistor® size 000/00 aR
Size 000 BS88, horizontal body, without indicator
BS000UB69V75 B330051 690 V 75 A
BS000UB69V80 C330052 690 V 80 A
BS000UB69V100 D330053 690 V 100 A
BS000UB69V110 E330100 690 V 110 A
BS000UB69V125 E330054 690 V 125 A
BS000UB69V160 F330055 690 V 160 A
BS000UB69V200 G330056 690 V 200 A
BS000UB69V250 H330057 690 V 250 A
BS000UB69V315 J330058 690 V 315 A
BS000UB50V350 X330116 500 V 350 A
BS000UB50V400 G330194 500 V 400 A
Size 000 BS88, horizontal body, with indicator
BS000UB69V75P H330126 690 V 75 A
BS000UB69V80P J330127 690 V 80 A
BS000UB69V100P K330128 690 V 100 A
BS000UB69V110P L330129 690 V 110 A
BS000UB69V125P M330130 690 V 125 A
BS000UB69V160P P330132 690 V 160 A
BS000UB69V200P Q330133 690 V 200 A
BS000UB69V250P R330134 690 V 250 A
BS000UB50V315P S330135 500 V 315 A
BS000UB50V350P T330136 500 V 350 A
BS000UB50V400P H330195 500 V 400 A
Size 00 DIN80, vertical body, for monitoring micro-contact
DN00UB69V16L V330275 690 V 16 A
DN00UB69V20L T330274 690 V 20 A
DN00UB69V25L M330268 690 V 25 A
DN00UB69V32L N330269 690 V 32 A
DN00UB69V40L P330270 690 V 40 A
DN00UB69V50L Q330271 690 V 50 A
DN00UB69V63L R330272 690 V 63 A
DN00UB69V80L D330237 690 V 80 A
DN00UB69V100L E330238 690 V 100 A
DN00UB69V125L F330239 690 V 125 A
DN00UB69V160L G330240 690 V 160 A
DN00UB69V200L H330241 690 V 200 A
DN00UB69V250L J330242 690 V 250 A
DN00UB69V315L K330243 690 V 315 A
DN00UB69V350L L330244 690 V 350 A
DN00UB69V400L M330245 690 V 400 A
Size 00 DIN110, vertical body, for monitoring micro-contact
DN00UB69V80D1L A330257 690 V 80 A
DN00UB69V100D1L B330258 690 V 100 A
DN00UB69V125D1L C330259 690 V 125 A
DN00UB69V160D1L D330260 690 V 160 A
N00UB69V200D1L E330261 690 V 200 A
DN00UB69V250D1L F330262 690 V 250 A
DN00UB69V315D1L G330263 690 V 315 A
DN00UB69V350D1L H330264 690 V 350 A
DN00UB69V400D1L J330265 690 V 400 A
